EMC Testing Equipment 10 KV Surge Simulator
- Fully compliant with the latest standards of IEC61000-4-5
- Large LCD interface display, Chinese or English menu, easy to use
- LCD display, Intelligent control, Use the Programmable imported high-voltage power supply, Reliable performance
- Programmable operation by a key setting
- Built-in international standards level parameters and user models parameters, simple
- Built-in intelligent couping / decoupling network. Testing safety
- Impulse injected the phase angle asynchronous or 0-360 掳 free to set
- The surge test Fully automatic switching without human operation
- Built-in the RS232 interface ,Remote operated by the optional control software.
- Description
- Inquiry
Advantage:
- Fully compliant with the latest standards of IEC61000-4-5
- Large LCD interface display, Chinese or English menu, easy to use
- LCD display, Intelligent control, Use the Programmable imported high-voltage power supply, Reliable performance
- Programmable operation by a key setting
- Built-in international standards level parameters and user models parameters, simple
- Built-in intelligent couping / decoupling network. Testing safety
- Impulse injected the phase angle asynchronous or 0-360 掳 free to set
- The surge test Fully automatic switching without human operation
- Built-in the RS232 interface ,Remote operated by the optional control software.
Parameter
| Open -circuit t voltage/short-circuit current | Open -circuit t voltage:聽聽聽聽聽1.2/50 渭 s聽锛屄0.2锝灺10kV Short-circuit current聽:聽聽8 /20 渭 s聽锛0.1锝灺5聽kA |
| Surge polarity | Positive聽/聽Negative/Asynchronism |
| Phase | Synchronism聽聽0 掳锝灺360 掳selectable/Asynchronism |
| Output impedance | Complex impedance锛毬2 惟聽聽12 惟 |
| Coupling path | Built-out,聽one phase three聽聽line,max 16A |
| Surge count | 1锝9999 |
| Surge interval | 10锝999S |
| Working power supply | AC220V 50/60Hz |
| Ambient temperature | 15鈩冿綖35鈩 |
| Outline dimensions | 480脳520脳320 |
