Lab Asphalt Bitumen Mixture Specimen Forming Machine
Lab Asphalt Bitumen Roller Compactor   It used to compact and prepare asphalt slabs specimen for wheel tracking test
- Description
- Inquiry
Lab Asphalt Bitumen Roller Compactor   It used to compact and prepare asphalt slabs specimen for wheel tracking test
Feature:
1.  The pressure of the grinding wheel is in the range 0-20KN,  arbitrary adjustment , and the precision is less than 0.1KN
2. The height of the test mold can be selected within the range of 30 to 100 minutes.
3. The clamping mechanism for installing the test mode is advanced, easy to use, safe and reliable.
4. After install the test mode on the trolley, it can be automatically centered.
5. the number of rolling of the car can be arbitrarily set, and the number of rolling can be recorded at any time, when the actual number of rolling reaches the set value, the rolling automatically stops.
6. set the rolling temperature arbitrarily according to the test requirements. When the actual temperature reaches the set temperature, the heating will automatically stopp and display the temperature value.
Parameter:
Number | Name | Technical indicators |
1 | Slabs size | Â Â Â Â Â Â Â Â Â 300x300x(30-100mm) |
2 | Roller diameter | 500mm, width: 300mm |
3 |         Roller force | 0-20KN free setting (set 9KN before shipment) |
4 |      Roller temperature | 0-200℃ |
5 |     Slabs mould speed | 6times/min ( back and force movement) |
6 | Â Â Â Â Â Â Â Â Dimension | 1216x640x1750mm |
7 | Â Â Â Â Â Â Â Â Â Weight | 300Kgs |
