Carbon Black Dispersion Tester Comply ISO 18553

Introduction:

Carbon black Dispersion Tester used to detect the dispersion of color and carbon black in polyolefin pipes, pipe fittings and mixed ingredients. By carbon black particles on the scale of the situation, shape, and distributed measurement, can build these parameters and mechanical properties, antistatic property, hygroscopicity of macro performance indexes such as inner link, this will be the quality of plastic material, production technology, new product research and development have a positive impact, promote enterprise and industry technical level to promote quickly at the same time.



The instrument in accordance with international standards of ISO 18553, the key parts adopt binocular microscope, high resolution, high resolution CCD camera, with powerful software support, can fast and accurately measure the size of the particles or particle group and its dispersion, all process automation, users only need to implement to add sample, software to realize the collection of particles images automatically, automatic save, automatic calculation of parameters.
Features:

1. The professional image analysis method is used to complete the determination of carbon black dispersion grade by computer, and the detection accuracy is high.
2. The particle size of the target carbon black can be analyzed from microns to millimeters
3. Equipped with professional microscope, equipped with 5 million CMOS image transmitter
4. The image can be saved in a single sheet, and the image size can be selected from four sizes: 640*480, 1024*768, 1280*1024, 2592*1944
5. Rich image processing functions to meet a variety of image processing needs
6. The software has automatic and manual methods for carbon black image segmentation
7. The software can meet the requirements of local analysis
8. Equipped with a micrometer ruler, which can calibrate the pixel point size, and the software has the function of moving the ruler, which can measure the distance between any two points
9. Customers can create their own standard library
10. The output results cover the number, particle size, area, etc. of carbon black pellets, and can be output in the form of data reports and excel
11. Provide image grayscale distribution map, particle size distribution map, particle size distribution map
12. The report results include: sample name, standard name, original image, grayscale image, etc. Report output formats are diverse, you can choose image format or pdf format to save.
13. The software has tried various mainstream operating systems, and has good compatibility with win7/win10/winXP, etc.
14. Using usb2.0 data interface, it can be adapted to a variety of acquisition devices (such as cameras or digital cameras)

Parameter:

  1. Detection range: 0.5um—1cm;

  2, imaging resolution 2592*1944 (5 million pixel CCD digital camera);

  3, optical magnification 100 times

  4. The illumination angle of the light source is 30°;

  5, image size 640*480, 1024*768, 2048*1536, 2592*1944;

  6. Analysis time The size of the selected image is different and slightly different;

  7. Instrument power supply 220V /2A/50Hz
