Digital Bottle Wall Thickness Gauge Tester

High Precision Digital Bottle Wall Thickness Gauge Tester  It is used to measure the thickness of the bottom and wall of glass bottles in the pharmaceutical, food, and pharmaceutical industries. It can be used to test the thickness of infusion bottles, beer bottles, oral liquid bottles, ampoules, vials and other products.

Features


Electronic digital display of measurement results, convenient for recording
Using capacitive sensor technology, convenient and practical
Meet the three test methods of glass bottle bottom thickness/wall thickness/bottle mouth thickness
Equipped with a micro printer to quickly print test results
Professional computer software USB connection, test process display, output and print function
Technical Parameter
Instrument range: 0-12.7mm/0.5″
Graduation value: 0.001mm/0.00005″
Sample diameter: 5-300mm
Sample height: ≤330mm
Instrument size: 480 mm (L) X430 mm (W) X560 mm (H)
Weight: 35Kg
